Small Portable Rig Soil Sample Exploration Farms SPT Core Drilling Machine Price

1 piece
MOQ
Small Portable Rig Soil Sample Exploration Farms SPT Core Drilling Machine Price
Características Galeria Descrição de produto Peça umas citações
Características
Especificações
Applicable Industries: Farms, Home Use, Retail, Construction works , Energy & Mining
Showroom Location: None
Condition: New
Type: water Drilling Rig
Power Type: Diesel
Usage: Water Well
Voltage: diesel engine
Dimension(L*W*H): 1940*1150*1900
Weight: 200 KG
Warranty: 1 Year
Marketing Type: New Product 2023
Machinery Test Report: Provided
Video outgoing-inspection: Provided
Warranty of core components: 1 Year
Core Components: Motor, Engine
Key Selling Points: Competitive Price
Drilling Diameter: 50mm
Drilling Depth: Max.100m
Mobility: yes
Product name: core drill machine
Model: LY130
Informação básica
Model Number: LY130
Condições de Pagamento e Envio
Packaging Details: Packed in wooden boxes
Supply Ability: 100 Piece/Pieces per Month
Descrição de produto
Product Description
Specification
Model(YY Sliding track.
)
LY-130Y/130YY
LY-180Y/180YY
LY-200Y/200YY
Drilling depth(m)
130
180
200
Open hole dia.(mm)
220
220
325
End hole dia.(mm)
75
75
75
Drill rod dia.(mm)
42-60
42-60
42-60
drill angle(°)
90-75
90-75
90-75
Matching power ( kW )
13.2
13.2
15
Weight without power ( kg )
560
610
1150
Rig Size L * W * H
Dimension ( mm )
2.4*0.7*1.4
2.4*0.6*1.4
2.7*0.9*1.6
Vertical shaft speed
Speed ( r/min )
142/285/570
130/300/480/730/830/1045
64/128/287/557
Vertical shaft travel
Stroke(mm)
450
450
450
Single rope lifting force
Max pull force(kg)
1600
2000
2400
Single-rope hoisting speed
Pull speed(m/min)
0.41-1.64
0.35-2.23
0.12-0.95
Wire rope diameter
Rope dia.(mm)
p9.3
p9.3
12.5
Wire rope capacity
Roll capacity(m)
27
35
35
Rated load
Rated load(ton)
2
2
5
Effective height
Height(m)
6
6
6
Flow rate
Dispalcement(L/min)
95
95
145
Maximum pressure
Max.pressure(Mpa)
1.2
1.2
2
Number of reciprocations
times(min)
93
93
93
Inlet hose dia. ( mm )
51
51
51
Outlet hose dia. ( mm )
32
32
32
Packing & Delivery
Company Profile
WE ARE FACTORY   VERIFIED MANUFACTURERS
Zhengzhou liyo Machinery Equipment Co., LTD was founded in 2002, the company is located in laizhou city, shandong province, China, covers an area of 20,000 square meters, the existing staff of more than 200 people, more than 30 senior engineers. We have a professional team of engineers with rich experience in the design and production of water well drilling rig . We provide good after-sales service to ensure the successful operation of our water well drilling rig . The company mainly produces various types of water well drilling rig in the drilling industry. This product is mainly used for drilling Wells, agricultural irrigation, geological exploration, geothermal air conditioning and other USES of Wells. For decades, the company follows the "quality first, customer first, honesty as the basis" business policy, quality and character coexistence, has won the trust and praise of the majority of users, best-selling products throughout the country, and export to foreign markets. We always adhere to the "quality brand, innovation and development" principle, to provide customers with high standards of products and satisfactory service we welcome customers at home and abroad to cooperate with us, mutual benefit and common development.
Certifications
WORK SHOP
Customer Photos
FAQ
Q 1:Are you manufacture?
A1:Yes,we are manufacture that more than 15 years experiences.
Q 2: What is the trade terms?
A 2: Normally with EXW, FOB Shanghai, CFR, CIP, CIF and DDU.
Q 3: Modes of shipment?
A 3: By sea, by railway, by air and by express.
Q 4:How long is your warranty?
A 4: One year warranty for machine and one year for core component.
Q 5:How to pay for it ?
A 5: L/C, T/T, D/P, cash, Alibaba trade assurance.
Q 6: Do you have instructions with the machine?
A 6: Yes,of course.All products comes with detailed instructions.
